Cheap Hole Drilling EDM

Cheap Hole Drilling EDM

Model No.︰DB703A

Brand Name︰BAOMA

Country of Origin︰China

Unit Price︰-

Minimum Order︰1 pc

Inquire Now

Product Description

Cheep Hole Drilling EDM DB703A

Parameters BMD703
Worktable size(L×W) mm 470x360
Table travel(X×Y) mm 400x320
Z axis travel mm 270+(300)
Max. drilling depth  mm 0 -- 300
Max. Drilling Speed  mm/min 60
Max. working current  A 30
Drill Diameter mm 0.3 -- 3.0
Load of table  Kg 300
Working solution   Water/Saponification
Water Tank L 30
Voltage   380V AC/50 Hz or 415V AC/50 Hz
Max. Power  KVA 3.5
Machine Dimension (LxWxH) mm 1120×1005×1915
Packing Size (LxWxH) mm 1400x1450x2050
Machine Weight Kg 700
Z Axis Controller type   Electric Motor
Digital Display   X,Y,Z axis
Function of setting depth   Yes



Price Terms: FOB Shanghai
Payment Terms: T/T or L/C at sight
Packing: 1 Case/Unit
Lead Time: 25days
Standards Certificate: CE; ISO9001; ISO14001
Embed HTML Code:

Item

DB703A

Worktable size(L×W)mm

470×360

Table travel(X×Y)mm

400×320

Z axis travel mm

300+(270)

Max. drilling depth mm

0-300

Max. drilling speed mm2/min

60

Max re-track speed of spindle mm/min

320

Max. working current A

30

Electrode diameter

0.3-3.0

Load of table kg

300

Working solution

Water/Saponification

Working reservoir capacity L

30

Power supply

380V AC/50 Hz or 415V AC/50 Hz

Max. Power consumption KVA

3.5

Machine dimension mm

1120×1005mm×1915

Package dimension mm

1400×1450×2050

Machine weight kg

700

Controller type

Automatic Z axis

Digital Display

X,Y,Z axis

Function of setting depth

yes

Function of group drilling

yes



The processing data in common use:   This section is some technologic data according to technics experiments of normal prototype machines and technologic results. In particular process, Users can choose different parameter according to different orders to gain the process result which user wants. Conditions: Electrode: brass power net: 380AC






parameters material aperture Ton(1) Toff (2) Ip (3) Kc(12) pressure(Mpa) processingvoltage (V) Rotation processingcurrent (A)
0.3 45# 2 1 2 0 5-6 25 Y 3
0.3 chilled steel 2 1 2 0 5-6 25 Y 3
0.3 stainless steel 2 2 2 0 5-6 25 Y 3
0.5 45# 3 2 3 0 6 25 Y 5
0.5 chilled steel 3 2 3 0 6 25 Y 5
0.5 stainless steel 3 2 2 0 6 25 Y 4
1.0 45# 3 2 5 - 6 20 Y 12
1.0 chilled steel 3 2 6 - 6 20 Y 12
1.0 stainless steel 3 2 4 - 6 20 Y 10
2.0 45# 4-6 2 6 = 6 20 Y 18
2.0 chilled steel 4-6 2 6 = 6 20 Y 18
2.0 stainless steel 5 2 6 = 6 20 Y 16
3.0 45# 5-7 2 8 = 6 20 Y 25
3.0 chilled steel 5-7 2 8 = 6 20 Y 25
3.0 stainless steel 7 2 7 = 6 20 Y 23



Control System: ZNC


Product Image

click for larger image

BMD703 ZNC EDM Hole Popper 2

Img 2

BMD703 ZNC EDM Hole Popper 3

Img 3

BMD703 ZNC EDM Hole Popper 4

Img 4

BMD703 ZNC EDM Hole Popper 5

Price Terms︰ FOB Shanghai

Payment Terms︰ TT / LC

Packing︰ Standard Export Plywood Case

Lead Time︰ Within 20 days

Standards Certificate︰ CE, ISO9001
